Steel Building Design with SOLIDWORKS Weldments


Release date:2018, June 17

Duration:00 h 59 m

Author:Gabriel Corbett

Skill level:Advanced


Exercise files:Yes

Jump-start your weldment design skills by learning to use SOLIDWORKS to create a steel building. This project-based course starts at the foundation: creating the planes, floor plan, and elevation sketches for a small shop building. Along the way, author Gabriel Corbett covers material selection, 3D sketching, and laying out structural members. Then together you’ll dive into creating welded and bolted corners, trimming and extending structural members for the best fit, and using gussets, bolt plates, and a foundation to define the structure of the building. The project ends with designing a custom weldment profile and generating frame drawings that can be handed off to manufacturing.

Topics include:

  • Creating the planes
  • Drawing 2D structures
  • 3D sketching
  • Choosing structural members
  • Creating the roof frame
  • Welding the structure
  • Assembling the weldment
  • Creating assembly and part detail drawings
  • Designing custom weldment profiles
Table of Contents

Welcome 1m 7s
Using the exercise files 50s
1. Basic Weldments Design
Creating the planes 4m 20s
Drawing the 2D structure 2m 8s
3D Sketching 1m 49s
Loading weldment profiles 4m 3s
Choosing the structural members 7m 13s
Patterning and mirroring structural members 5m 4s
2. Frame Layout
Creating the roof frame 6m 30s
Adjusting the corners 1m 17s
Adding in holes 4m 6s
Adding in gussets 1m 55s
Welding the structure 1m 39s
3. Weldment Assembly
Assembling the roof 4m 3s
Creating a custom weldment profile 3m 40s
Mirroring and patterning assemblies 2m 11s
4. Frame Drawings
Assembly drawing 2 m 58s
Part detail drawing 4m
Next steps 49s
