HBIM – Historic Building Re-creation

On October 8, 2018

In 2D Drawing , 3D Drawing , Architecture , AutoCAD , Lynda , Rendering

Release date:2015, November 12

Duration:04 h 34 m

Author:Paul F. Aubin

Skill level:Advanced

Language:English

Exercise files:Yes

Today’s technology allows architectural enthusiasts to take a step back in time and explore celebrated designs of the past. Project Soane is a crowd-sourced mission to resurrect Sir John Soane’s lost Bank of England design using modern BIM software. In this course, Paul F. Aubin shows how you can use Revit to rebuild history and submit your own contributions to historical reconstruction projects like Project Soane. He also shows how to create stunning renderings of the finished model using Revit, Showcase, and 3ds Max.

NOTE: Registration for the rendering phase of Project Soane opens in January 2016. Render the Revit or RBX models in your favorite Autodesk software for the chance to win great prizes from HP and NVIDIA.

Topics include:
Researching source materials and source drawings
Sketching and modeling architecture
Setting up the project in Revit
Modeling overall forms
Using system families
Adding details such as columns and moldings
Creating an interior model
Rendering the project

Table of Contents

Introduction
Welcome 53s
Using the exercise files 1m 3s
1. What Is Project Soane?
What is Project Soane? 4m 42s
Take a look at a model 6m 42s
How to join the project wiki 6m 10s
2. Corinthian Low-Detail Versions
Building the Tivoli corner columns 5m 1s
Strategy for building the columns 3m 27s
Working with seed families 8m 34s
Understanding the course detail version 12m 31s
Overview of the medium detail version 8m 33s
Using a massing rig to build the abacus 11m 56s
Understanding the medium volutes 10m 13s
Understanding classical column entasis 10m 50s
Building elliptical entasis 7m 51s
Medium detail fluting 10m 35s
3. Starting the Fine Detail Version
Fine detail column base 10m 33s
Fine detail shaft 12m 34s
Proportional scaling workaround 7m
Fine detail abacus 11m 23s
Fine detail flower bud 9m 49s
Fine detail flower petals 9m 56s
Creating spline paths 10m 3s
Fine detail small volute 11m 9s
Fine detail large volute 11m 46s
4. Continuing the Fine Details
Building the leaf structure 11m 15s
Building the leaf form 10m 45s
Establishing context 6m 23s
Fine detail foliage 8m 59s
5. Assembling the Corinthian Column
Assembling the fine detail capital 8m 54s
Assembling the fine detail column 11m 15s
Placing the columns in Tivoli corner 4m 17s
Rendering 8m 44s
Conclusion
Goodbye 48s
